8 2 Gigabit Port PoE Ethernet Switch Cat5/5e/6 Standard Network Cable With 1 SFP Port

Product Categories
Shenzhen Newbridge Communication Equipment Co.,Ltd
Contact Now

8 2 Gigabit Port PoE Ethernet Switch Cat5/5e/6 Standard Network Cable With 1 SFP Port

Brand Name : NEWBRIDGE

Model Number : ND1P803FGX

Certification : FCC,CE

Place of Origin : SHENZHEN,CHINA

MOQ : 1PC

Price : Negotiation

Payment Terms : T/T , Western Union

Supply Ability : 3000pcs per month

Delivery Time : According to the quantiy and stocking , 3-4 working days after payment

Packaging Details : packing can be done by customer's requested, usually used in carton

Power Adapter Voltage : AC 110V-240V

POE Ethernet Port : 1～8 Port : 10/100Mbps

Transmission Medium : Cat5/5e/6 standard network cable

Working temperature : 0℃~55℃

PoE Power : af=15.4W (every port)

Weight : 723g

Contact Now

POE Output 8+2 Gigabit Port Ethernet Switch with 1 SFP port

1. Overview

8 2 Gigabit Port PoE Ethernet Switch Cat5/5e/6 Standard Network Cable With 1 SFP PortNewbridge® The switch is a compact 8+3 port PoE Switch,With 8*10/100Mbps PoE Switch, 2* 10/100/1000Mbps Uplink Ports and 1*10/100/1000Mbps SFP Port(combo),The 8*PoE ports can automatically detect and provide power for any connected 802.3af Powered Device(PD),such as VOIP phones,IP Cameras, All PoE ports support the IEE802.3af standard,with a maximum output of 15.4w each port.

2.Feature

8 2 Gigabit Port PoE Ethernet Switch Cat5/5e/6 Standard Network Cable With 1 SFP Port

l 8x 10/100Mbps auto-sensing RJ45 ports,8x 10/100Mbps PoE ports, 2*10/100/1000M uplink port,1 x SFP port(combo)

l Unique Feature:one-key CCTV mode,which can restrain network storm,realize VLAN function and1~8 downlink ports only able to communicate with uplink ports. The communication distance extends to 250 meters

l Supports port auto-flip (Auto MDI/ MDIX);

l Built-in power supply;

l Maximum power of single PoE port: 15.4W;

l Maximum PoE power: 120W;

l Adopts store-and-forward architecture;

l IEEE 802.3af/at power on up to 8 ports

l Fanless, natural cooling, small,compact and quiet design, suitable for desktop or wall

3．Application Diagram

8 2 Gigabit Port PoE Ethernet Switch Cat5/5e/6 Standard Network Cable With 1 SFP Port

  • Dimensions

8 2 Gigabit Port PoE Ethernet Switch Cat5/5e/6 Standard Network Cable With 1 SFP Port

5. Specifications

Item Description
Power Power Adapter Voltage AC 110V-240V
Consumption 120W

Network Connector

Network Port

 POE Ethernet Port 1～8 Port : 10/100Mbps
Ethernet port Uplink Port : 10/100/1000Mbps

SFP Port

SFP Port: 10/100/1000Mbps

Transmission Distance

1～8 Port : 100Mbps:0~100m;

10Mbps: 0~250m;
Uplink Port : 0 ~ 100m

SFP: depends on the optical module(Combo)
Transmission Medium Cat5/5e/6 standard network cable

Network Switch

 Network Standard

IEEE802.3/802.3u,

IEEE802.3x,IEEE802.1D
Switching Capacity 4.8G
Packet Forwarding 5.65Mpps
MAC Table 2K

Power Over Ethernet

 PoE Standard IEEE 802.3af
PoE Power Supply End-Span(1/2+;3/6-)
PoE Power af=15.4W (every port)

LED Status Indicator

PoE Ethernet

LED Indicator

 Power: 1 red light indicates that the power normal work;
POE: 8 yellow lights indicate that the POE is power on;
Ethernet: 11 green lights indicate that the Ethernet Link and Act;

Environmental

 Working temperature 0℃~55℃
Relative Humidity 20~95%
Storage temperature -20℃~70℃

Mechanical

 Dimension (L×W×H) 202mm*140mm*45mm
Color Black
Weight 723g
Stability MTBF >30000h

6. Order Information

Part No Description of product Unit
ND1P803FGX 11 ports switch with 8*10/100M bit PoE ports,2*10/100/1000M Uplink Port and 1*SFP combo,PoE Standard: IEEE 802.3af,PoE data & power transmission distance 100meters(100Mbps),250meters(10Mbps) pc
